Laminar Flow Cabinet

LORDERAN Benchtop Small Vertical Laminar Flow Cabinet with Touch Screen, Compact Laboratory Clean Bench, HEPA Filtered

SKU
V600-1
Availability
In stock
Questions

Ask about this instrument

LORDERAN Benchtop Small Vertical Laminar Flow Cabinet with Touch Screen, Compact Laboratory Clean Bench, HEPA Filtered

An engineer replies by email or phone, usually within 12 hours.

Model · V600
Power · 110V

A compact benchtop clean bench that gives a single user an ISO Class 5 work zone in a 600 mm footprint, for plant tissue culture, media preparation and sterile sample handling. Room air passes a washable pre-filter and an H14 HEPA filter, then falls vertically over the work surface at 0.2–0.45 m/s and leaves through the front. A 7-inch color touch screen runs the whole cabinet. It protects the sample, not the operator.

ISO 5clean grade, Class 100
H14HEPA, ≥99.995% at 0.3 μm
0.2–0.45m/s vertical airflow
600 mmbenchtop width
50 kgnet weight
Plant tissue cultureMedia preparationElectronics and optics assemblySterile sample handlingTeaching labs

Does it protect the operator?

No. It protects the sample by blowing clean air toward you. For infectious or hazardous materials, choose a Class II biosafety cabinet.

Will it fit my bench?

It is 600 mm wide, 460 mm deep and 700 mm tall, with a 505 × 345 × 375 mm work zone.

How far does the window open?

Up to 240 mm; a hidden counterweight holds it where you set it, and an alarm warns when it is above the set height.

Which power does it need?

110 V or 220 V. Rated power includes a 500 VA load for the work-area socket.

BKCB-V600 Benchtop Laminar Flow Cabinet datasheet (6 pages)

Full specifications, laminar airflow, HEPA filtration and ISO Class 5 reference data, installation and warranty in one document to share with your team.
Download datasheet

Clean air that falls straight down

A fan draws room air through the pre-filter and pushes it through the HEPA filter above the work zone. The clean air moves down in parallel streams, so particles shed by hands or tools are carried away instead of drifting onto the sample.

HEPARoom air in through the pre-filterHEPA filter, H14Laminar downflow 0.2–0.45 m/s, out at the frontPositive pressure keeps room air out

Section through the cabinet. Four sides are kept at positive pressure.

≤ 0.5CFU / 30 min colonies
≤ 65 dB(A)noise
≥ 300 lxlighting
≤ 5 μmvibration (rms)
  • Positive-pressure surround on the left, right, rear and bottom sides.
  • Fan and front window interlock, plus UV lamp, front window and lamp interlock.
  • Alarms for front window out of set height, filter over-pressure and filter replacement.
  • One-key disinfection and scheduled timing from the touch screen.

What ISO Class 5 means

ISO 14644-1 sets the most particles of 0.5 μm and larger that a cubic meter of air may hold: 3,520 for ISO Class 5. Per liter, the volume of a large bottle, that is about three or four particles; each class above allows ten times more.

ISO 5 · this bench≤ 3.5 per literISO 6≤ 35 per literISO 7≤ 352 per literISO 5≤ 3.5 per literISO 6≤ 35 per literISO 7≤ 352 per liter

Limits from ISO 14644-1 for particles ≥ 0.5 μm, shown per liter (1/1000 m³). Ordinary indoor air is typically ISO 8 to 9, up to 3,520 to 35,200 particles per liter. Class 100 is the older US FED-STD-209E name for ISO 5.

What a clean bench protects

A laminar flow cabinet blows clean air over the work and out toward you, so it keeps the sample clean but sends anything the sample releases into your face and the room. For infectious material, choose a Class II biosafety cabinet; for chemical fumes, a fume hood.

Laminar flowthis cabinetClass II BSCbiosafety cabinetFume hoodductedSampleOperatorExhaust filteredLaminarflowClass IIBSCFumehoodSampleOperatorExhaust filtered

ISO Class 5 on a benchtop

The V600 brings the clean grade of a full-size clean bench to a single workstation, with toughened glass on three sides for a clear view.

ISO 5clean grade (Class 100)

ISO 14644-1 Class 5 allows no more than 3,520 particles of 0.5 μm or larger per cubic metre of air.

99.995%HEPA H14 at 0.3 μm

The most penetrating particle size is captured at least 99.995% of the time.

505 × 345 × 375mm internal work zone
240 mmmaximum front opening

Hidden counterweight keeps the manual window where you set it.

Small footprint, full feature set

Everything a full-size clean bench offers, sized for one person and a crowded bench.

Control

  • 7-inch color touch screen with live running status
  • Appointment (scheduled) timing
  • One-key disinfection
  • Front window height monitoring
  • Filter status monitoring

Safety

  • Fan and front window interlock
  • UV lamp, front window and lamp interlock
  • Front window height alarm
  • Filter over-pressure alarm
  • Filter replacement alarm

Build

  • Vertical-surface cabinet design
  • Cold-rolled steel body
  • 304 stainless steel work surface
  • 5 mm tempered front and side glass
  • Initial-effect pre-filter

Specifications

Model BKCB-V600, available in 110 V and 220 V versions.

Model BKCB-V600
Dimensions
External Size (W × D × H) 600 × 460 × 700 mm
Internal Size (W × D × H) 505 × 345 × 375 mm
Front Window Safety Height 200 mm
Max Opening 240 mm
Net Weight 50 kg
Gross Weight 62 kg
Package Size (W × D × H) 740 × 600 × 860 mm
Airflow and cleanliness
Flow Mode Vertical Flow
Airflow Velocity 0.2 m/s to 0.45 m/s
Clean Grade ISO Level 5 (100 levels)
Filtration Efficiency HEPA (H14) high efficiency filter, filtration efficiency for 0.3 μm particle≥ 99.995%
Safety Colonies Number ≤ 0.5CFU/30 min
Performance
Number of Users Single
Noise ≤ 65 dB(A)
Lighting ≥ 300lx
Vibration ≤ 5 μm(rms)
Rated Power 650VA (including operating area socket load 500VA)
Accessories
Standard Accessory LED lamp*2, UV lamp*2, Waterproof socket*2

Questions buyers ask

Warranty, returns, delivery and quotes.

What does the warranty cover?

A 3-year worldwide warranty from the date of purchase, covering core components and controls. We repair first; if a major defect can’t be repaired, we replace the unit or give a full refund. HEPA filters, seals and other wear parts are excluded.

Can I return it?

Yes, within 30 days of delivery if unused and in original condition. For non-quality returns the buyer pays return shipping, a 3% restocking fee and the card processing fee. Defective or damaged items are covered in full.

How is it delivered, and when does it ship?

Freight, duties and taxes are paid to your loading dock; moving the cabinet inside is not included. Your confirmed ship date is included in the order acknowledgement.

Can I get a formal quote for a purchase order?

Yes. Select your size and options, then click Get a quote for a PDF quotation with DDP shipping included.

Choose your voltage

The price and PDF quote update with your choices.

Configure yours
